NO.1 You have an Azure subscription.
Users access the resources in the subscription from either home or from customer sites. From home,
users must establish a point-to-site VPN to access the Azure resources. The users on the customer
sites access the Azure resources by using site-to-site VPNs.
You have a line-of-business app named App1 that runs on several Azure virtual machine. The virtual
machines run Windows Server 2016.
You need to ensure that the connections to App1 are spread across all the virtual machines.
What are two possible Azure services that you can use? Each correct answer presents a complete
solution.
NOTE: Each correct selection is worth one point.
A. a public load balancer
B. Traffic Manager
C. an Azure Content Delivery Network (CDN)
D. an internal load balancer
E. an Azure Application Gateway
Answer: D,E
NO.2 You have an Azure subscription that contains two virtual networks named VNet1 and VNet2.
Virtual machines connect to the virtual networks.
The virtual networks have the address spaces and the subnets configured as shown in the following
table.
You need to add the address space of 10.33.0.0/16 to VNet1. The solution must ensure that the hosts
on VNet1 and VNet2 can communicate.
Which three actions should you perform in sequence? To answer, move the appropriate actions from
the list of actions to the answer area and arrange them in the correct order.
https://examclubs.com3
Answer:
Explanation:
Step 1: Remove peering between Vnet1 and VNet2.
You can't add address ranges to, or delete address ranges from a virtual network's address space
once a virtual network is peered with another virtual network. To add or remove address ranges,
delete the peering, add or remove the address ranges, then re-create the peering.
Step 2: Add the 10.44.0.0/16 address space to VNet1.
Step 3: Recreate peering between VNet1 and VNet2
References:
https://docs.microsoft.com/en-us/azure/virtual-network/virtual-network-manage-peering
