Which is NOT one of the steps used in the glass box method? Correct Answer: rotate object in glass box
The three standard views of an object are ______. Correct Answer: top, front, right side
What is the order of
...
Which is NOT one of the steps used in the glass box method? Correct Answer: rotate object in glass box
The three standard views of an object are ______. Correct Answer: top, front, right side
What is the order of precedence of lines in a drawing? Correct Answer: object, hidden, center
What type of feature is parallel to the surface being dimensioned? Correct Answer: dimension line
A ______ dimension is described in inches per foot. Correct Answer: shaft taper
To establish on a drawing that 1/4 inch equals 1 inch, the designer would write ______. Correct Answer: 1/4 = 1
Section lines on a blueprint include _______. Correct Answer: a surface that has been cut
In a threaded fastener assembly what is designed to protect the threads? Correct Answer: shank
The minor diameter of a screw thread is measured at the ______. Correct Answer: root of screw thread
The minor diameter of a threaded fastener is ______. Correct Answer: the major diameter minus the thread height
How do you determine the grade of a bolt? Correct Answer: number of lines on the head +2 indicates the grade
A screw with National fine thread is represented on a drawing with what designation? Correct Answer: NF
Metals treated by ______ processes become soft. Correct Answer: annealing
A running fit is also called a(n) ______. Correct Answer: sliding fit
The term ______ refers to a physical portion of a part. Correct Answer: feature
A(n) _______ is a theoretically perfect line, point or pane that is located by a similar feature or part. Correct Answer: datum
GD&T _________________. Correct Answer: allows certain tolerances on part features to be increased
