Rheobase Correct Answer the lowest point on a strength duration curve at an infinitely long pulse duration
Chronaxie time Correct Answer the pulse width at twice the rheobase value. It approximates the most efficient
...
Rheobase Correct Answer the lowest point on a strength duration curve at an infinitely long pulse duration
Chronaxie time Correct Answer the pulse width at twice the rheobase value. It approximates the most efficient stimulation pulse duration
Charge (formula) Correct Answer Charge= I(current) x T(time)
Energy (formula) Correct Answer Energy(microjoules)= I(current)xVxT
Functional Refractory Period Correct Answer the coupling interval which first results in a measurable degree of delay in impulse conduction
Effective Refractory Period Correct Answer the longest coupling interval to be associated with block
Devices with NO interaction with pacers Correct Answer 1. microwave oven, 2. CT scan/Ultrasound 3. X-rays (diagnostic)
Devices that cause transient or 1 beat inhibition Correct Answer 1. EAS 2. Cellphones 3. Arc Welding 4. airport metal detector 5. TENS 6. Electric appliances such as electric blanket & power tools
Devices that may damage the pacemaker Correct Answer 1. MRI 2. Defibrillator 3. Cardio version 4. Cautery/RF Ablation 5. Radiation Therapy
Resistance in Series Correct Answer Series means the beginning of one resistance is connected to another
Sum the resistances: R1+R2= total resistance. EX: A LEAD FRACTURE (fractures INCREASE impedance)
Resistance in Parallel Correct Answer Parallel means all the resistances are connected to the same point.
(R1xR2)/(R1+R2)= total resistance
EX: LEAD INSULATION DEFECTS (insulation defects DECREASE impedance)
Permanent pacemakers are constant voltage or constant current? Correct Answer ALL permanent pacemakers are constant voltage devices.
