In this experiment, the heat engine consists of an aluminum canister
connected by tubing to a piston. The work is done by the air inside the
system which expands when it is immersed in hot water. The expanding air
pushes on a piston and does work by lifting a weight. The heat engine cycle is
completed by immersing the can in cold water, which returns the air
pressure and volume to the starting values.
A
The theoretical maximum efficiency of a heat engine depends only on the
temperature of the hot reservoir TH and the temperature of the cold
reservoir TC . The maximum efficiency is given by
e
max=(1−T TC H)× 100 (1)
The actual efficiency is defined as
e=
WQH
× 100 (2)
where W is the work done by the heat engine on its environment and
QH is the heat extracted from the hot reservoir.
We will use Equations 3-5 below to analyze our heat engine.
According to the First Law of Thermodynamics,
ΔU=Q−W (3)
where ΔU is the change in internal energy of the gas, Q is the heat
added to the gas ( Q is negative when heat is removed), and W is the
work done by the gas ( W is negative when work is done on the gas).
7/8/2015 1:53 PM
The Heat Engine
Lab
20
1P H Y S I C S L A B O R A T O R Y M A N U A L
You may recall that the equation relating the heat to the temperature change
for a substance of heat capacity C is
