MSSC Quality Certification Test Prep

Document Content and Description Below

MSSC Quality Certification Test Prep Which is NOT one of the steps used in the glass box method? - ✔✔rotate object in glass box The three standard views of an object are ______. - ✔✔top, fro ... nt, right side What is the order of precedence of lines in a drawing? - ✔✔object, hidden, center What type of feature is parallel to the surface being dimensioned? - ✔✔dimension line A ______ dimension is described in inches per foot. - ✔✔shaft taper To establish on a drawing that 1/4 inch equals 1 inch, the designer would write ______. - ✔✔1/4 = 1 Section lines on a blueprint include _______. - ✔✔a surface that has been cut In a threaded fastener assembly what is designed to protect the threads? - ✔✔shank The minor diameter of a screw thread is measured at the ______. - ✔✔root of screw thread The minor diameter of a threaded fastener is ______. - ✔✔the major diameter minus the thread height How do you determine the grade of a bolt? - ✔✔number of lines on the head +2 indicates the grade A screw with National fine thread is represented on a drawing with what designation? - ✔✔NF Metals treated by ______ processes become soft. - ✔✔annealing A running fit is also called a(n) ______. - ✔✔sliding fit The term ______ refers to a physical portion of a part. - ✔✔feature A(n) _______ is a theoretically perfect line, point or pane that is located by a similar feature or part. - ✔✔datum GD&T _________________. - ✔✔allows certain tolerances on part features to be increased A feature control frame is not used to describe ______. - ✔✔measurements A common decimal inch rule graduation is in _______. - ✔✔50ths A scale typically found on a machinist rule is _______. - ✔✔1/16 Resolution is sometimes called ______. - ✔✔discrimination A common fractional inch rule graduation is in _______. - ✔✔32nds One inch is equal to _______. - ✔✔25.4mm A typical dial caliper can be used to measure dimensions to the nearest ________ inches. - ✔✔0.001 Calibration means to ______. - ✔✔adjust a device to a standard The typical accuracy of a dial caliper is about ______ inches. - ✔✔0.003 The accuracy of a digital caliper reading is about ______ inches. - ✔✔0.003 A micrometer increments how far for each complete rotation of its thimble? - ✔✔0.025 Company standards dete [Show More]
