Electrical Engineering _The diagram below shows a sequential circuit that has two control inputs A and B along with two outputs Q and Q'. The output from the upper NAND gate is defined as Q; the output from the lower NAND gate is defined as Q'.
Document Content and Description Below
The diagram below shows a sequential circuit that has two control inputs A and B along with two outputs Q and Q'. The output from the upper NAND gate is defined as Q; the output from the lower NAND ga... te is defined as Q'. a) (3) If A = 0 and B=1 what is the value for Q (0 or 1)? Screen Shot 2021-04-01 at 9.24.11 AM.png b) (3) If A = 1 and B=0 what is the value for Q (0 or 1)? c) (3) Suppose that A = 0, B=0 and Q=0. What happens to the value of Q if both A and B are then set to 1? d) (3) If Q=0 initially, what is the value of Q if both A and B are set to 1? e) (3) If Q=1 initially, what is the value of Q if both A and B are set to 1? Engineering & Technology Electrical Engineering [Show More]
