CT212 W5Assignment.docx CT-212 Grantham University CT-212 5-7. Write the Boolean equation for the circuits of Figure P5-7. Simplify the equations and draw the simplified logic circuit. W = (A + ... B) BC W = BC X = (A + B) (B + C) X = B + AC Y = A + (A + B) BC Y = A + BC Z = AB + B + BC Z = B 5-8. Repeat Problem 5-7 for the circuits shown in Figure P5-8. a. X = (B + C) + (A + B) · (B + C) X = B + C b. Y = A · (A + B) · (B + C) Y = A (B + C) c. Z = A · B + (A · B) · (B + C) Z = A · B 5-9. Draw the logic circuit for the following equations. Simplify the equations and draw the simplified logic circuit. a. V = AC + ACD + CD V = C(A+D) b. W = (BCD + C) CD 5-10. Construct a truth table for each of the simplified equations of problem 5-9. A. V = C(A+D) ABC A+D V=C(A+D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [Show More]
